Product Overviews
Tube ice machine is one kind of ice machine. Because of the irregular length and hollow tube, so we called it tube ice, its inside diameter is 5 mm to 15 mm ,the length is between 25 mm ~ 42 mm, there are a variety sizes that can be chosen, the outer diameter of ice are: 22, 29, 32, 35 mm,etc. Thiskind of ice is called tube ice. Tube ice is round, generous, bright and transparent, so it is welcomed by consumer, it is widely used in modulating drinks, ice beverage, decoration and food fresh keeping, etc.
Feature of tube ice machine:
1. The evaporator using high quality stainless steel 304 and other materials processing, meet international health standards;
2. The machine adopts the integrated design, compact structure, easy installation and use;
3. PLC man-machine interface computer module, ice making and ice automatically switches off, save time and effort;
4. All equipment using CAD, 3D simulation assembly, arrangement of equipment parts and accessories, pipe to more reasonable,compact structure and not crowded, operation, maintenance more human;
5. According to different working condition of customized, non-standard machines can be made.
Machine Parameter
| Model |
Rated output |
Input power |
Rated
current
|
Refrigerating
capacity
|
Cooing way |
Unit size (mm) |
| BMT10 |
1ton/24h |
4.6kw |
9.2A |
8.9kw |
Air / Water cooling |
1490*900*1850 |
| BMT20 |
2ton/24h |
8.3kw |
16.6A |
17.7kw |
Air / Water cooling |
1490*900*1850 |
| BMT30 |
3ton/24h |
11.8kw |
23.6A |
25.4kw |
Air / Water cooling |
1490*900*1850 |
| BMT50 |
5ton/24h |
17.35kw |
43.5A |
40kw |
Air / Water cooling |
1490*900*1850 |
| BMT80 |
8ton/24h |
32kw |
64A |
67.5kw |
Air / Water cooling |
1490*900*1850 |
| BMT100 |
10ton/24h |
40kw |
80A |
82.6kw |
Air / Water cooling |
1490*900*1850 |
| BMT150 |
15ton/24h |
55.5kw |
110A |
121.4kw |
Air / Water cooling |
2750*1680*3500 |
| BMT200 |
20ton/24h |
70kw |
140A |
166kw |
Air / Water cooling |
2960*2100*3550 |
| BMT250 |
25ton/24h |
92kw |
184A |
205kw |
Air / Water cooling |
3400*2350*3750 |
| BMT300 |
30ton/24h |
115kw |
230A |
215kw |
Air / Water cooling |
3950*2350*4050 |
Ice Making Display
Main Configuration
Application Industry
Company Profile
Jiangsu ICEMA refrigeration technology co., LTD. Is a technology-based enterprise that pay attention to user experience. According to customer requirements,Company can produce intermediate,low and ultra low temperature refrigeration system,covering cooling, keeping fresh, cold storing,freezing,quick freezing and other fields,our machines not only have a large market share in china, and also be exported to Southeast Asia, Africa,Middle East,South America ,Europe and other countries.
Company Certificate
Other Products
Customer Visit
Customer Praise
FAQ
1. Can I customize the machine?
You can choose output, material, accessories brand, etc.
2 . How can I trust your company?
We have more than ten years' experience in exporting. Our customers are in many countries and cities around the world. We delivered the goods to our customers safely and on time every time. You can confirm your order on our Alibaba.com or Made in China website, and they will also provide guarantee for your order.
3. How long will it take to make the machines?
The production time required for machines of different output is different. Peak season requires longer production time.
4. How do I receive the goods?
After we reach an agreement, I will entrust a freight forwarder to deliver the goods to your designated port. When the goods arrive at the port, you can go to the port to pick them up with the bill of lading.
5. The address of the company?
Our company is located in Changzhou, Jiangsu Province, but we also have an international affairs office in Shanghai. If you want to visit our company, you can take a plane to Shanghai, and then our company will take care of all your travel.
