Product Details
Place of Origin: Shanghai, China
Brand Name: ICEMA
Certification: ce
Model Number: BMSB50
Payment & Shipping Terms
Minimum Order Quantity: 1 SET
Price: $3,000.00/sets 1-1 sets
Packaging Details: wooden case or plywood box or container or as per requests
Delivery Time: 20 DAYS
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 2 Unit/Units per Month 2018 block ice machine china
Rated Output: |
5T/24H |
Cooling Capacity: |
38.5KW |
Ice Temp: |
-8℃ |
Input Power: |
44.6KW |
Rated Current: |
888.8A |
Compressor: |
Piston Compressor |
Compressor Power: |
17.43KW |
Condensation Method: |
Ari/Water Cooling |
The Refrigerant: |
R404A/R507A |
Machine Size: |
8200*2900*3500mm |
Rated Output: |
5T/24H |
Cooling Capacity: |
38.5KW |
Ice Temp: |
-8℃ |
Input Power: |
44.6KW |
Rated Current: |
888.8A |
Compressor: |
Piston Compressor |
Compressor Power: |
17.43KW |
Condensation Method: |
Ari/Water Cooling |
The Refrigerant: |
R404A/R507A |
Machine Size: |
8200*2900*3500mm |
Model | output (kg) |
Cooling (kw) |
input (kw) | Rated current (A) | refrigerant | compressor power(kw) | ice weight(kg/pc) | machine size(L*W*Hmm) |
BMB20 | 2T | 14 | 7.7 | 14.3 | R22/R404A | 6.43 | 20/30/50kg | 4150*1650*2480 |
BMB30 | 3T | 21.5 | 11 | 21.4 | R22/R404A | 9.74 | 20/30/50kg | 5000*1800*2480 |
BMB50 | 5T | 35.9 | 18 | 35.6 | R22/R404A | 16.2 | 20/30/50kg | 5700*2200*2480 |
BMB80 | 8T | 56.7 | 30.7 | 61.4 | R22/R404A | 27 | 20/30/50kg | 6300*2200*2480 |
BMB100 | 10T | 77.3 | 37.5 | 75 | R22/R404A | 33.7 | 20/30/50kg | 6450*2360*2530 |
BMB120 | 12T | 85 | 41.35 | 82.7 | R22/R404A | 37.3 | 20/30/50kg | 7100*2350*2690 |
BMB150 | 15T | 106.8 | 59.3 | 116.6 | R22/R404A | 49.3 | 20/30/50kg | 8670*2750*2690 |
BMB200 | 20T | 147 | 85.8 | 170.6 | R22/R404A | 75.1 | 20/30/50kg | 8960*3250*2690 |
BMB250 | 25T | 210 | 92.4 | 184.8 | R22/R404A | 83.2 | 20/30/50kg | 11400*3250*2690 |
BMB300 | 30T | 230.8 | 107 | 214 | R22/R404A | 92 | 20/30/50kg | 12950*3250*2690 |
Model | output (kg) |
Cooling (kw) |
input (kw) | Rated current (A) | refrigerant | compressor power(kw) | ice weight(kg/pc) | machine size(L*W*Hmm) |
BMSB10 | 1T | 8.6 | 4.9 | 9.6 | R22/R404A | 4.15 | 20/30/50kg | 4200*1600*1500 |
BMSB20 | 2T | 15.78 | 8.04 | 16 | R22/R404A | 7.11 | 20/30/50kg | 5000*1600*1500 |
BMSB30 | 3T | 21.5 | 12.37 | 24.3 | R22/R404A | 9.74 | 20/30/50kg | 5600*1900*1600 |
BMSB50 | 5T | 38.5 | 21.56 | 43.12 | R22/R404A | 17.43 | 20/30/50kg | 6400*2600*1600 |
BMSB100 | 10T | 77.3 | 44.6 | 88.8 | R22/R404A | 36.7 | 20/30/50kg | 7600*2600*1750 |
BMSB150 | 15T | 115 | 62.7 | 125 | R22/R404A | 53.3 | 20/30/50kg | 9600*2600*1750 |
BMSB200 | 20T | 147 | 90.5 | 181 | R22/R404A | 75 | 20/30/50kg | 10400*3000*1800 |
BMSB250 | 25T | 194 | 97 | 194 | R22/R404A | 85.5 | 20/30/50kg | 9200*4100*1800 |
BMSB300 | 30T | 234.8 | 125 | 250 | R22/R404A | 103 | 20/30/50kg | 10300*4500*1800 |
BMSB400 | 40T | 308 | 147 | 294 | R22/R404A | 121.5 | 20/30/50kg | 12300*4500*1800 |
BMSB500 | 50T | 368 | 185.6 | 378 | R22/R404A | 150 | 20/30/50kg | 12300*5400*1800 |
BMSB600 | 60T | 455.8 | 215 | 428 | R22/R404A | 181.5 | 20/30/50kg | 13800*5400*1800 |
