10 Tons Ice Machine with Customizable Automatic Packing and 22x22x22 mm Cube Ice Size

Name: 10 Tons Ice Machine with Customizable Automatic Packing and 22x22x22 mm Cube Ice Size
Brand: ICEMA
SKU: ICEMA
Rating: 4.9 (164 reviews)

Product Details

Place of Origin: Jiangsu, China

Brand Name: ICEMA

Payment & Shipping Terms

Minimum Order Quantity: 1set

Price: negotiable

Packaging Details: Wooden case

Delivery Time: 30days

Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability: 1000 Set/Sets per Month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                10 Tons Ice Machine, Automatic Packing Ice Machine, 22x22x22 Ice Machine


Applicable Industries:	Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C	Condition:	New
Ice Shape:	Cube	Voltage:	220V/380V
Power:	43.6KW, 43.6KW	Dimension(LWH):	7120x1660x2100mm
Weight:	40 KG	Warranty:	1 Year
Key Selling Points:	Automatic	Ice Storage Capacity:	20KG
Machinery Test Report:	Provided	Video Outgoing-inspection:	Provided
Warranty Of Core Components:	1 Year	Core Components:	Pressure Vessel, Pump, PLC
Compressor Brand:	Emerson, Bitzer, Daikin	Application:	Industrial
Model:	BMC10T	Output:	10T/24H
Condenser:	Air/water Cooling	Refrigerant:	R404A/R22
Rated Current:	114A	Rated Voltage:	220V/380V
Cube Ice Size:	22x22x22 Mm	Machine Size:	7120x1660x2100mm
Custom Ice Size:	Support

Applicable Industries:	Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C
Condition:	New
Ice Shape:	Cube
Voltage:	220V/380V
Power:	43.6KW, 43.6KW
Dimension(LWH):	7120x1660x2100mm
Weight:	40 KG
Warranty:	1 Year
Key Selling Points:	Automatic
Ice Storage Capacity:	20KG
Machinery Test Report:	Provided
Video Outgoing-inspection:	Provided
Warranty Of Core Components:	1 Year
Core Components:	Pressure Vessel, Pump, PLC
Compressor Brand:	Emerson, Bitzer, Daikin
Application:	Industrial
Model:	BMC10T
Output:	10T/24H
Condenser:	Air/water Cooling
Refrigerant:	R404A/R22
Rated Current:	114A
Rated Voltage:	220V/380V
Cube Ice Size:	22x22x22 Mm
Machine Size:	7120x1660x2100mm
Custom Ice Size:	Support

10 Tons Ice Machine with Customizable Automatic Packing and 22x22x22 mm Cube Ice Size

Shanghai ICEMA refrigeration technology co., LTD. Is a technology-based enterprise that pay attention to user experience. According to customer requirements,Company can produce intermediate,low and ultra low temperature refrigeration system,covering cooling, keeping fresh, cold storing,freezing,quick freezing and other fields,our machines not only have a large market share in china, and also be exported to Southeast Asia, Africa,Middle East,South America Europe and other countries.

According to the developing requirement of the market, ICEMA refrigeration technology co., LTD., has developed a group of standard machines for customers in all industries,including brine refrigeration block ice machine, direct refrigeration block ice machine(high quality aluminum plate),tube ice machine, seawater type flake ice machine, freshwater type flake ice machine,plate ice machine, slurry ice machine,cube ice machine,water chiller,rake ice storage, spiral ice storage, fruits,vegetables and meat cold storage, spiral ice feed system, etc.

Recommend Products

ICEMA industrial cube ice machine is mainly used in bars, supermarkets, restaurants, hotels, ice stores and other filed. Output from 2 tons to 10 tons.

Why choose us

● Safety: the industrial ice machine uses SUS304 stainless steel as the main raw material, with special water flow design, and automatic cleaning function, to ensure that the production of ice clean health, edible.

● Full output: used in high temperature environment in summer, the output can reach 100%. When used in low temperature environment in winter, the yield can reach 100%~150%

● Stable performance: ice crystal hard, crystal clear, soluble, can be long-term storage.

● The whole processing is automatically and it can reduce your cost in worker.
● Ice dropping and outgoing automatically, reduce the possibility of contact by human, which can guaranty the ice clean and sanitary.

● Provide 18 months extra long warranty period. The seller offers free technical guidance.

Product Description

Model	Rated output	Input power	Rated current	Refrigerating capacity	Ice tray	Cooling way
BMC20	2ton/24h	8.73kw	30A	12.24kw	19206	Air/water Cooling
BMC30	3ton/24h	15.45kw	35A	30kw	192010		Air Cooling
BMC40	4ton/24h	22.95kw	46A	41.3kw	192014		Air Cooling
BMC50	5ton/24h	27.75kw	52A	47kw	192018		Air Cooling

Export packing method: standard wooden case.
Completely ice machine contain: ice machine, cooling tower, water pump, water pipes and water pipe fittings.
Machine come into use, customer only need prepare water and power for the machine.

Configuration

Compressor

A variety of famous brands and models of compressors are available

1. Bitzer--Germany

2. Frascold--Italy

3. Refcomp--Italy

4. Copeland--America

Evaporator

1. Red copper plated ice plate, up to food standards. 2. Every ice tray with 19*20 grids. 3. The quantity of ice tray of ice cube is different with different output.

2T--6 trays

3T--10 trays

4T--14 trays

5T--18 trays

Condenser

Due to the different condensing methods, air-cooled condensers and water-cooled condensers are used respectively.

Expansion Valve

1. All valve parts of the machine use danfoss brand.

2. Quality assurance, longer service life

Control System

Use the remote control system 1. Add fault alarm function, monitor machine running state at any time 2. No need for 24 hours on duty, save manpower 3. The machine can be controlled remotely by mobile phone or computer, which is more convenient to use

Delivery Ice System

1. Stainless steel ice bin and stainless steel screw

2. Automatic ice feeding, reduce manual contact, ensure ice clean, save labor

Factory

Business Partner

Application Field

FAQ

1. How can I contact you?
You can contact me here. You can also contact me through Tel/Whatsapp/Wechat +86 18136585859, Email: dorsey@sh-icema.com.

2. Can I customize the refrigerator?
Yes. You can choose size, material, accessories brand, etc.

3. Are the prices on the website accurate?
No. Because the price of the machine is affected by many factors, the price of the website is not very accurate.

4. How do I get a more accurate price?
Tell the salesman your requirements and they will give you a more accurate price.

5. Is there any guarantee for my payment?
In Alibaba, we paid the margin. This is to protect your rights. In addition, After you receive the goods, Alibaba will release
your payment to us.

6. How do I receive the goods?
After we reach an agreement, I will entrust a freight forwarder to deliver the goods to your designated port. When the goods arrive at the port, you can go to the port to pick them up with the bill of lading.
