Product Details
Place of Origin: Jiangsu, China
Brand Name: ICEMA
Certification: CE
Model Number: BMSF10
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: $29,100.00/sets 1-2 sets
Packaging Details: Wooden boxes or into container
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 2 Set/Sets per Month
Output: |
1T/24H |
Cooling Capacity: |
6.5KW |
Ice Temp: |
-12℃ |
Input Power: |
5.9KW |
Rated Current: |
11.8A |
Compressor: |
Piston Compressor |
Compressor Power: |
4.6KW |
Condensation Method: |
Ari/Water Cooling |
The Refrigerant: |
R404A/R507A |
Machine Size: |
950*800*680mm |
Output: |
1T/24H |
Cooling Capacity: |
6.5KW |
Ice Temp: |
-12℃ |
Input Power: |
5.9KW |
Rated Current: |
11.8A |
Compressor: |
Piston Compressor |
Compressor Power: |
4.6KW |
Condensation Method: |
Ari/Water Cooling |
The Refrigerant: |
R404A/R507A |
Machine Size: |
950*800*680mm |
Model | output (kg) |
Cooling (kw) |
input (kw) | Rated current (A) | refrigerant | compressor power(kw) | ice size(mm) | machine size(L*W*Hmm) |
BMSF10 | 1T | 6.5 | 5.9 | 11.8 | R507A/R404A | 4.6 | 1.5-2.5mm | 1320*970*680 |
BMSF20 | 2T | 12.7 | 11.3 | 22.6 | R507A/R404A | 8.6 | 1.5-2.5mm | 1500*1100*1050 |
BMSF30 | 3T | 18.4 | 15.8 | 31.6 | R507A/R404A | 12.3 | 1.5-2.5mm | 1745*1360*1250 |
BMSF50 | 5T | 32.8 | 27.7 | 55.4 | R507A/R404A | 22.7 | 1.5-2.5mm | 2200*1500*1600 |
BMSF80 | 8T | 49 | 41 | 82 | R507A/R404A | 36 | 1.5-2.5mm | 2740*1900*1690 |
BMSF100 | 10T | 67.5 | 57.8 | 115 | R507A/R404A | 52.5 | 1.5-2.5mm | 2740*1900*1830 |
Model | output (kg) |
Cooling (kw) |
input (kw) | Rated current (A) | refrigerant | compressor power(kw) | ice size(kg/pc) | machine size(L*W*Hmm) |
BMSF10 | 1T | 6.5 | 5.9 | 11.8 | R507A/R404A | 4.6 | 1.5-2.5mm | 1320*970*680 |
BMSF20 | 2T | 12.7 | 11.3 | 22.6 | R507A/R404A | 8.6 | 1.5-2.5mm | 1500*1100*1050 |
BMSF30 | 3T | 18.4 | 15.8 | 31.6 | R507A/R404A | 12.3 | 1.5-2.5mm | 1745*1360*1250 |
BMSF50 | 5T | 32.8 | 27.7 | 55.4 | R507A/R404A | 22.7 | 1.5-2.5mm | 2200*1500*1600 |
BMSF80 | 8T | 49 | 41 | 82 | R507A/R404A | 36 | 1.5-2.5mm | 2740*1900*1690 |
BMSF100 | 10T | 67.5 | 57.8 | 115 | R507A/R404A | 52.5 | 1.5-2.5mm | 2740*1900*1830 |
