Flake Ice Making Machine for High Productivity in Industrial Fishing Operations

Name: Flake Ice Making Machine for High Productivity in Industrial Fishing Operations
Brand: ICEMA
SKU: ICEMA
Price: 30 USD
Availability: InStock
Rating: 4.9 (193 reviews)

Brand Name:	ICEMA
Price:	$30,700.00/pieces 1-3 pieces
Supply Ability:	1000 Set/Sets per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Jiangsu, China

Applicable Industries:

Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C

Condition:

New

Ice Shape:

Flake Ice

Voltage:

220V/380V

Power:

48.6

Dimension(L*W*H):

2740*1900*1830mm

Weight:

655 KG

Warranty:

1 Year

Key Selling Points:

High Productivity

Ice Storage Capacity:

Cold Room

Machinery Test Report:

Provided

Video Outgoing-inspection:

Provided

Warranty Of Core Components:

1 Year

Core Components:

Pressure Vessel, PLC, Expansion Valve, Evaporator, Condensor

Compressor Brand:

Emerson, Frascold, Bitzer, Refcomp, Hanbell

Application:

Industrial, Ocean Fishing

Product Name:

Ice Flake Making Machine

Keyword:

Flake

Compressor:

Emerson/Bitzer

Refrigerant:

R404A/R22

Insulation Material:

PU Material

Ice Making Speed:

12-17 Minutes / Time

Evaporator:

Copper Plated Nickel Ice Mold

Packaging Details:

Wooden case/Container

Supply Ability:

1000 Set/Sets per Month

Highlight:

High Productivity Ice Flake Making Machine

Industrial Flake Ice Making Machine

Product Description

Flake Ice Making Machine for High Productivity in Industrial Fishing Operations 0

Products Description

Flake Ice Making Machine for High Productivity in Industrial Fishing Operations 1

FLAKE ICE MACHINE DESCRIPTION

Flake ice, it is a kind of irregular flaky ice. Size is different; the biggest flake size is about 30.5mm*30.5 mm, thickness of 1.5 mm - 2.5 mm. Because of its dry, safe to contact by the characteristics of the cooling material ,so it is widely used in hotels, supermarkets, chemical industry, construction and deep-sea fishing, etc.
The freezing principle of flake ice machine is simple, put the city water directly (can also be equipped with water filter) into the cold water tank of assembling unit, When the refrigeration system begins to work, the closed loop heat exchange of refrigerant, outside water flow into the tank, the water is pumped into the water distribution pan by the
circulating pump, driven by the reducer, the water in the pan evenly flows down the inner wall of evaporate, the refrigerant in the refrigeration system evaporates through the loop inside the evaporator and absorbs large amount of heat by exchanging heat with the water on the wall, as a result, the water flow over the surface of inner evaporator wall sharply cools to below the freezing point and freezes into ice instantaneously, Part of the water film attached the bottom of evaporator and then into the water for recycling, when the ice on the inner wall reaches a certain thickness, the spiral ice skates is driven to peel ice from the inner wall, thus ice flakes form, fall into the ice storage bin at the bottom of ice flakes and stored for future cycling.
Generally speaking, the flake ice can fall into the storage in 30 seconds; stop making ice in 2 minutes after machine turned off.

Flake Ice Making Machine for High Productivity in Industrial Fishing Operations 2

FUTURES AND SUITABLE INDUSTRY

Features：
1. SUS316 stainless steel evaporator;
2. The frame is made of SUS316 stainless steel or hot dip galvanized steel;
3. Use deep groove piston compressor and special water condenser, longer service life;
4. The water-cooled aircrew need not equipped with cooling tower, can significantly
reducecustomer costs;
5. Can be directly installed on the fishing boat, it is more convenient to use.

Suitable industry：
1. The dock or the place need to use the sea ice;
2. The fishing boats, Making ice is suitable for deep-sea fishing.

Flake Ice Making Machine for High Productivity in Industrial Fishing Operations 3

Flake Ice Making Machine for High Productivity in Industrial Fishing Operations 4

Flake Ice Making Machine for High Productivity in Industrial Fishing Operations 5

Flake Ice Making Machine for High Productivity in Industrial Fishing Operations 6

Flake Ice Making Machine for High Productivity in Industrial Fishing Operations 7

Flake Ice Making Machine for High Productivity in Industrial Fishing Operations 8

Flake Ice Making Machine for High Productivity in Industrial Fishing Operations 9

Product Paramenters

Model	Output	Refrigerate Capacity	Total Power	Rated Current	Compressor Power	Refrigerant	Cooling Way	Unit Size LWH (mm)
BMSF10	1T	6.5KW	5.9KW	11.8A	4.6KW	R507/R404A	Air/Water	1320970680
BMSF20	2T	12.7KW	11.3KW	22.6A	8.6KW	R507/R404A	Air/ Water	150011001050
BMSF30	3T	18.4KW	15.8KW	31.6A	12.3KW	R507/R404A	Air/Water	174513601250
BMSF50	5T	32.8KW	27.7KW	55.4A	22.7KW	R507/R404A	Air/Water/ Evaporative	220015001600
BMSF80	8T	49KW	41KW	82A	36KW	R507/R404A	Air/ Water/ Evaporative	274019001690
BMSF 100	10T	67.5KW	57.8KW	115A	52.5KW	R507/R404A	Air/ Water/ Evaporative	274019001830
